SPECIFICATIONS:

Interface

• 48× 10/100/1000 Mbps RJ45 Ports (8× PoE++, 40× PoE+)

• 4× 1/10 Gbps SFP+ Slots**

• 1× USB 2.0 Port

• 1× RJ45 Console Port

• 1× USB Type-C Console Port

Fan Quantity 3

Power Supply 100-240 V~ 50/60 Hz

PoE Ports (RJ45)

• Standard: 802.3af/at/bt compliant

• PoE++ Ports: Ports 1~8 (up to 90W per Port)

• PoE+ Ports: Ports 9~48 (up to 30W per Port)

• Power Budget: 770W*

• Fast PoE

• Perpetual PoE

Dimensions ( W x D x H ) 17.3 × 13.0 × 1.7 in (440 × 330 × 44 mm)

Mounting Rackmountable

Advanced Features

• Automatic Device Discovery†

• Batch Configuration†

• Batch Firmware Upgrading†

• Intelligent Network Monitoring†

• Abnormal Event Warnings†

• Unified Configuration†

• Reboot Schedule†

ISP Features:

• 802.3ah Ethernet Link OAM

• L2PT (Layer 2 Protocol Tunneling)

• Device Link Detect Protocol (DLDP)

• DDM

• sFlow

VLAN

• Max 4K VLAN Group (802.1q VLAN)

• 802.1Q Tagged VLAN

• MAC VLAN Entries: 60

• Multicast VLAN

• Management VLAN

• VLAN VPN (QinQ): Max 256 entries

• GVRP

• Protocol VLAN: Protocol Template 16, Protocol VLAN 12 entries

• Voice VLAN

• Private VLAN

Management Features

Omada App - Yes. Requiring the use of the Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller

Centralized Management

• Omada Cloud-Based Controller

• Omada Hardware Controller

• Omada Software ControllerCloud AccessYes. Requiring the use of the Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.Zero-Touch ProvisioningYes. Requiring the use of the Omada Cloud-Based Controller.

Package Content

• SG5452XMPP Switch

• Power Cord

• Console Cable

• Rackmount Kits

• Rubber Feet

• Quick Installation Guide
